MB-R16FXP stands out for its very compact size, that allows for mounting in a standard 19" rack, using the optional adapters, the complete endowment of signal sends and returns and the practical configuration of the controls, that result in a simple and immediate utilization. It is fitted with a dual Montarbo® stereo effects processor, based on a powerful, latest generation, 56 bit DSP, that provide 2 x 205 high quality programs, with an uncompromised sound quality (thanks to the dual 24 bit conversion) mated with unusual ease of use. MB-R16FXP incorporates a dual channel class-D power amplifier rated at 750 + 750 W EIAJ. The switch-mode power supply results in a minimal weight, and the very high efficiency minimizes the emission of heat, thus increasing the system's reliability and prolonging it's working life.
Features
- D.E.Co (Dynamic EQ. Controller): sophisticated speaker protection circuit.
- Internal stereo electronic cross-over that may be bypassed for wide-band use.
- 134 dB max SPL.
- 2 x 15" transducers - custom designed to Montarbo specifications - featuring neodymium alloy magnets and light-alloy die-cast frames, which ensure significant weight reduction.
- The cabinet is built with birch multiply and painted with black, heavy duty, antscratch paint; it is fitted with side handles. The front side is protected by a strong, powder coated, metal grille.
Applications
- Suitable for both indoor and outdoor use
- Stadiums
- Arenas
- Concert halls
- Medium to large theatres
- Medium to large clubs
- Large-scale events
Specifications
| Acoustic Data | |
| Frequency Response [-3dB] | 34 Hz – 100 Hz |
| SPL 1W @ 1mt | 103 dB |
| Max SPL | 134 dB |
| Dispersion (HxV) | omni |
| LF | 2 x 15” |
| LF Voice Coil | 4” neodymium |
| LF Type | bass reflex |
| Amplifier | |
| Amp Class | AB MosFet |
| Peak Power | 1200 Watt |
| RMS Power | 850 Watt |
| Self-rotating display | No |
| Processor | |
| Controller | No |
| AD/DA Converter | No |
| System Presets | No |
| Limiter | Yes |
| Dual Active Peak, RMS, Thermal | Yes |
| Input Section | |
| Signal input | Dual XLR stereo input |
| Signal Out | Dual Line and X-Over |
| USB Connector | No |
| Mechanics | |
| Flyable | No |
| Handles | Yes |
| Pole mount | Yes |
| Width | 940 mm |
| Height | 570 mm |
| Depth | 490 mm |
| Weight | 63 Kg |
